Asuga XLR Green Large Scale 4WD Monster Buggy - RTR from Team Corally - COR00288-G
The Team Corally Asuga XLR is a high-performance off-road racing buggy that is designed to dominate any terrain it encounters. With its sleek and aerodynamic design, the Asuga XLR is not only visually appealing but also incredibly agile and fast.
Fifteen percent bigger than the average 1/8 buggy, with higher ground clearance, more suspension travel, and oversized components-in short, a completely new chassis that still uses the proven drive components of Corally's existing 6S models. Note the many details, and it will soon become clear to you that the ASUGA XLR has set a new standard for RTR RC cars.
The precision CNC-manufactured aluminum parts, the beautiful red anodization, and the various small details make all the difference.
Visit the Official Team Corally Asuga XLR Large Scale 4WD Monster Buggy Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
 |
Aluminum Chassis with Composite Side Guards A 3mm thick, 6065 Aluminum main chassis delivers offers unyielding strength, while the molded side guards protect against dirt and debris from electronics or drivetrain. A mount for the ESC on/off switch has been conveniently molded in the LH side guard. |
 |
Extreme Front Chassis Brace The optimized front chassis brace solidifies the front bulkhead, front tower, steering system and Ackermann brace into a rigid, durable assembly that ensures precision steering and the durability that you’ve come to expect from Team Corally. The optimal combination of aluminum and composite components allows drivers to bash with confidence knowing that the Asuga is prepared to dominate anything in its path. |
 |
Heavy Duty Composite Suspension Arms Completely re-thinking the arm design, Team Corally designers went all-in toward durability and precision without creating a weight penalty. Further innovations are expressed by the anodized aluminum hinge pin and pivot ball retainers that provide additional strength and security to critical suspension components previously vulnerable during extreme bashing sessions. |
 |
Premium Spring Steel Outdrives The Asuga XLR shares drivetrain components proven from use on the venerable Kronos XTR, with S2 Spring Steel providing the ideal combination of tensile strength, light weight, and durability. Enjoy competition-level quality driveline components in a premium bash buggy machine. |
 |
Heavy-Duty Steering Blocks The freshly designed composite steering knuckles offer improved fitment and security for the pillow balls and virtually eliminates any chance of them popping out as a result of hard landings or crashes. |
 |
Low Profile Rebel XMS Tires Using a common 17mm drive hex, the Asuga XLR features impact resistant 130mm diameter wheels with Rebel XMS high-grip tires designed especially for the rigors of 6S bashing. |
Features:
- Modern shaped front and rear bumpers with skid plate
- Oversized composite steering links and rear camber links
- Oversized composite camber links
- Ultra-rigid hybrid chassis brace system
- Oversized (13mm thick) HD composite suspension arms with aluminum anti-tear rings
- Front upper arm wing
- CNC-Machined 8mm aluminum suspension arm holders
- CNC-Machined 8mm aluminum suspension arm holder
- Oversized HD composite "Pillow Ball" steering blocks with anti pop-out design
- CNC-Machined 5mm aluminum shock towers
- The suspension arm holders are fixed to the chassis with M4 screws
- Super smooth 16mm "Big Bore" aluminum shock absorbers
- High performance precision CNC-cut hardened steel spur gear
- Differential spiral bevel gears and pinions
- Strong and Wear-resistant S2 hardened spring steel drive joints and wheel shafts
- CNC-Machined adjustable aluminum motor mount
- Large battery holder
- Low profile Rebel XMS Off-Road tire
Includes:
- Team Corally Asuga XLR Blue Large Scale 4WD Monster Buggy - RTR
- 2.4 GHz 2-channel transmitter
- Team Corally Kuron 825 Brushless Motor
- Hobbywing Torox 185 ESC
- Team Corally CR-HV 7225 Digital Servo
- Full set of ball bearings, rubber sealed
Requires:
- 4x AA batteries for 2.4GHz radio transmitter - we recommend Admiral 1.2V 2600mAh NiMH AA Rechargeable Batteries (4 Pack
- 4S to 6S (14.8V to 22.2V) LiPo Battery with XT90 connector - we recommend the Admiral 5300mAh 4S 14.8V 60C Hard Case LiPo Battery with XT90 Connector
- 4 Cell to 6 Cell compatible battery charger - select a minimum 4 cell (4S) charger from our Charger Collection
Product Specifications:
Model Scale |
N/A |
Length |
574mm / 22.6in |
Width |
359mm / 14.1in |
Height |
192mm / 7.6in |
Weight (No Battery) |
4450g / 157.0oz |
Wheelbase |
371mm / 14.6in |
Ground Clearance |
75mm / 2.9in |
Body |
Composite |
Chassis |
Painted, Decals Applied |
Drivetrain |
4WD |
Wheel Size (Diameter x Width) |
130mm x 51mm |
Wheel Hex Size |
17mm |
Tire Tread |
Offroad |
Bushing Material |
N/A |
Suspension |
Independent |
Shock Type |
Oil-Filled |
Transmission |
N/A |
Gear Pitch |
N/A |
Internal Gear Ratio |
3.31 (MOD.1) |
Final Drive Ratio |
13.23 (MOD.1) |
Pinion |
N/A |
Spur Gear |
N/A |
Differential |
Oil-Filled |
Ball Bearings |
Full |
Brakes |
N/A |
Electronic Speed Control |
Hobbywing Torox 185 ESC |
Motor |
Team Corally Kuron 825 Brushless |
Battery |
4S - 6S LiPo with XT90 connector (required) |
Max Battery Dimensions (L x W x H) |
51 x 161 x ?mm (2 x 6.3 x ?") |
Servos |
Team Corally CR-HV 7225 Digital Servo |
Radio |
2 Channel (included) |
Lights |
No |
Sound |
No |
Water Resistant |
Yes |
Skill Level |
Intermediate |
Assembly Time |
Less Than 1 Hour |
Recommended Environment |
Outdoors |
Videos
Product Videos
Q&A
Product questions & answers
NOTE: Questions submitted on this page are answered by customers who have previously purchased this item. If you have a support related question that requires immediate assistance, please visit our Help Center
Support
Product support
Product Manuals:
- Team Corally Asuga XLR Large Scale 4WD Monster Buggy Instruction Manual
- Team Corally Asuga XLR Large Scale 4WD Monster Buggy Quick Start Guide
- Team Corally CTR2 Transmitter Instruction Manual
- Team Corally Torox 185 ESC Instruction Manual
