A-6 Intruder High Performance 80mm EDF Jet - PNP from Freewing - PNP - FJ20415P
Version Info: This is the High Performance version of the Freewing A-6 Intruder. This version includes a 100A ESC and hybrid metal gear servos. As of 11/8/2023 this model now comes with the upgraded 3658-2150Kv inrunner brushless motor and a newly designed 12-Blade EDF.
During its service life, the Grumman A-6 Intruder was the US Navy and Marine Corps premier close combat, mid-wing attack aircraft. The Intruder was in service between 1963 and 1997 and was designed as an all-weather medium attack aircraft to replace the piston-engined Douglas A-1 Skyraider.
The A6 Intruder is easily one of the most requested models, so we wanted to offer an EDF jet that would stand apart from its competitors. As you've come to expect from Freewing Model, the A6 intruder is loaded with scale features and performance componentry. In this high performance version, the new 80mm 12-blade EDF is powered by a powerful 2150Kv inrunner motor for awesome speed and incredible maneuverability. The sound produced from the new 12-blade EDF will simply blow you away.
Additional upgraded features include a 100A Hobbywing ESC, 9g hybrid metal gear precision servos, electronic retracts with full metal shock absorbing struts, and scale drop down flaps. Own one of the most sought after, highly detailed, best built RC foam jet on the market - the Freewing A-6 Intruder.
Features:
- Model officially licensed by Northrop Grumman.
- NEW! 12-Blade factory balanced EDF with metal housing combined with a powerful brushless 3658-2150Kv inrunner motor
- 100 Amp Hobbywing ESC with 5A BEC
- Hybrid metal gear servos throughout
- Super scale details include two hand painted pilots, full instrument panel, refueling probe, scale drop tanks, airfoil panel lines, and complete USS Forrestal graphics package
- Electronic retractable landing gear with all metal shock-absorbing struts
- Steerable, shock absorbing nose gear for enhanced ground maneuverability
- Full function drop down flaps allow shorter take-off distances and slow, scale landings
- Full function linked horizontal stabilizer/elevator gives incredible climb and descent capability and true to life scale detail
- Carbon spars and EPO foam construction provide the perfect balance between strength and flexibility
- Nylon hinges on all control surfaces (superior to foam hinges)
- Outrunner motor, servos, ESC and EDF come pre-installed for your convenience.
Requires:
- 6 Channel radio - select a minimum 6 channel radio from our Radio Collection
- 6 Channel receiver - select a minimum 6 channel receiver from our Receiver Collection
- 6 Cell 22.2V 4000 mAh LiPo Battery with EC5 connector - we recommend the Admiral Pro 4000mAh 6S 22.2V 60C LiPo Battery with EC5 Connector
- 6 Cell compatible battery charger - select a minimum 6 cell (6S) charger from our Charger Collection
Power System and Electronics Compatibility:
This model is designed to operate using the included ESC and its integrated BEC, which is specifically matched to the onboard electronics. To ensure reliable performance and prevent damage, always power the aircraft's receiver and electronics through the installed ESC using the main flight battery. Do not use any power source other than the main flight battery to power the model, otherwise damage will occur to the electronics.
The receiver, servos, and other onboard electronics included with this model are rated for a maximum input voltage of 5.5V. When selecting your ESC and power system, verify that the BEC output supplied to the receiver and onboard electronics does not exceed 5.5V. Using a higher voltage will damage the aircraft's electronics.
Product Specifications:
|
Wingspan |
1170mm / 46in |
|
Length |
1200mm / 47.2in |
|
Flying Weight |
2260g / 79.7oz |
|
CG (Center of Gravity) |
Check manual |
|
Power System |
3658-2150Kv Brushless Inrunner Motor |
|
Electronic Speed Control |
100A ESC, 5A BEC, EC5 Connector |
|
Propeller / EDF |
80mm EDF with 12-Blade Fan |
|
Servos |
|
|
Landing Gear |
Electronic retractable main gear and steerable nose gear with all metal shock absorbing struts |
|
Required Battery |
6S 22.2V 4000mAh 60C LiPo |
|
Required Radio |
6 Channel |
|
Ailerons |
Yes |
|
Elevator |
Yes |
|
Rudder |
Yes |
|
Flaps |
Yes |
|
Lights |
No |
|
Hinge Type |
Nylon hinges |
|
Material |
EPO Foam |
|
Skill Level |
Advanced |
|
Build Time |
2 Hours |
|
Recommended Environment |
Outdoor |
